VX-1500

Vertical Machining Center

Technical Specs Print Specs

Loading Capacity kg (lb) 2,000 (4,400)
Rapid Traverse (x/y/z) m/min (in/min) 36/36/36 m/min (1,417.3 in/min)
Spindle Speed RPM 15,000:BT40 Standard
15,000:BT50 Option
Tool Taper #40 - CAT #40/BT #40 STD
(HSK-A63 OPT)
#50 - CAT #50/BT #50/ HSK-A100 OPT
Number of Tools 48:BT40 Standard
60:BT40 Option
30:BT50 Option
NC System Matsuura G-Tech 31i
Working Surface mm (in) 1,700 x 700 (66.92 x 27.55)
Travel (x/y/z) mm (in) 1,524/700/610
(60.00/27.55/24.01)
Industries Die / Mold
